MAGNETIC LATCHES

Tecnica Design magnetic latches provide the perfect solution for ultra-quiet residential applications. With no protruding bolt or strike lip, these latches offer a clean, minimalist look to homeowners looking to create unique flush-to-wall installations free of unsightly strikes, hinges or bolts.

NOTE: Tecnica Design levers with magnetic latch do not have the same features or characteristics:

FEATURES

Meets ADA requirements

For doors 1¹⁄₈ to 2″ (35 to 51 mm) thick
Non-handed
Fixed 2³⁄₈″ (60 mm) backset; 2³⁄₄″ (70 mm) backset available
Magnetic latch* with ergonomic 30° activation
Standard faceplate with square corners
Quiet operation
Available with round or square rose
Privacy function with auto-release
Concealed mounting screws
Magnetic, no-lip strike* with square corners
Requires the same tools and preparation as classic tubular latches
Pair with invisible hinges for unique flush-to-wall door installations

(*)Strike and latch use strong neodymium (rare earth) magnets

LEVER STYLES

CIRCA

LINEA

THE FLAT

FUNCTIONS

10Passage*
42Privacy, with auto-release*
-5Dummy

(*) Available as magnetic latches – see Magnetic tab for details.

FINISHES

15 SATIN NICKEL

19 MATTE BLACK

Other finishes available
Approximate finish simulation, for reference only

DOCUMENTATION

Product Page

Tecnica Design Collection – 01.210
Tecnica Design (Magnetic Latches) – 01.220

Installation Instructions

100 Tecnica Design – Installation Instructions
M6-100 Tecnica Design (Magentic) – Installation Instructions
100-5 Tecnica Design – Installation Instructions, Dummy

Templates & Door Preparations

Residential Door Preparation – 70 mm
Residential Door Preparation – M100
